Description

The all-new PRO-PLOW 3 line of straight blade plows offers the first stainless steel straight blade model from Western Products. With limited moving parts and full hydraulic range of motion–these straight blade plows are workhorses that move snow efficiently season after season.

Features

• Structural Reinforcement - Eight vertical ribs paired with the exclusive POWER BAR provides structural reinforcement for exceptional torsional strength and rigidity to eliminate blade twisting. High-strength steel at the base channel offers added support to the bottom of the plow blade.

• Reliable Hydraulics - We manufacture our own hydraulic components to ensure the highest standards of quality and reliability, so that you get a hydraulics system that’s not only fast and responsive, but that’s built to last season after season. Fully enclosed components are protected from the elements.

• Trip Protection - The full trip blade uses two springs to protect your plow and vehicle when striking hidden obstacles while plowing. Elastomeric bumpers reduce jarring and soften the blade return when tripping occurs. For added dampening, shock absorbers are available as an accessory.

• Light Bar - Be seen and recognized with the standard, WESTERN red light bar on both stainless steel and powder-coated steel options. Not only does this boost the aesthetic appeal of your snowplow and increase visibility—it also signifies quality, reliability, and professionalism.

• Nighthawk™ Snow Plow Headlights - Available in both LED and Dual-Halogen models, NIGHTHAWK plow lights are engineered and tested for maximum light output, performance and durability to keep you ahead of the storm.

• UltraMount® 2 Snowplow Mounting System - The UltraMount^® 2 system is designed for fast and easy installation and removal using a simple mechanical system. It features a robust one-piece design and is 100% compatible with UltraMount^® system mounts and electrical platforms.

• Chain Lift System - The mechanical chain lift system offers a variety of performance and reliability advantages over a hydraulic system. Main benefits include cleaner scraping performance, higher stacking capabilities, reliability, and easy recovery in the event of a breakdown.

• Fleet Flex Electrical System - WESTERN hopper spreaders are designed with FLEET FLEX technology for easy interchangeability between electric hopper spreaders without having to change the wiring or the controls. It provides easy operation, increased reliability, simple wiring, and easy installation. Additionally, accessories automatically integrate into the control for easy plug-and-play.

• Plow Control Options - Choose between a CabCommand hand-held control with push buttons or a joystick control, based on operator preference. For efficient, precise and intuitive blade control while plowing, both controls feature power “on” and “float” LED lights, backlighting for night operation, and plug-in connector for easy removal.

• Security Guard Anti-Theft System - The exclusive WESTERN^® SECURITY GUARD^™ snowplow anti-theft system is a safe and secure way to electronically lock your snow plow when it is detached from your truck as a deterrent from theft. Unlike physical locks that can easily be cut or removed, the system allows you to electronically lock the snowplow’s hydraulic functions, rendering your plow inoperable to unauthorized users.

• Isolation Module - This advanced snow plow light and electrical system features improved electrical pins in the harness for trouble-free connections. An underhood module improves system life and complies with OEM requirements. No toggle switch needed to change from vehicle to plow lights.

• ULTRAFINISH™ Baked On Powder Coat - The ULTRAFINISH^™ baked on powder coat with epoxy primer is standard on all WESTERN^® plows, providing outstanding protection against wear and rust.

• Pre-Punched Blades for Accessories - The blade is pre-punched for easy installation of accessories, providing a custom fit. The pre-punched holes also prevent damage to the powder coat that can sometimes occur when installing an accessory.

Specifications

• Blade Width: 8'
• Moldboard Options: Powder-Coated
• Blade Type: Straight Blade
• Vehicle Compatibility: Truck Class 2 - 3 & Tractors
• Approximate Weight (Without Mount): Powder-Coated: 617 lbs
• Plowing Width (At 28 Degrees): 84.8"
• Blade Height: 29"
• Blade Thickness: 14 ga
• Trip Springs: 2
• Ribs: 8
• Lift Cylinder (Single-Acting): 1.5" x 8"
• Angling Rams (Single-Acting): 1.5" x 10"
• Cutting Edge: 3/8" x 6" (Standard)
• Mount Type: UltraMount 2
