Description

Standard with Manual Angle. One-Cylinder and Two-Cylinder Hydraulic Angle options available.

Features

• 4° Side-to-side oscillation follows uneven surfaces
• Angle the blade 28° left or right
• Trip edge protects operator & equipment
• 5/8" x 6" reversible steel bolt-on edge allows 3-1/2" of wear

Specifications

• Width: Overall, Straight / Full Angle (Inches): 61.0 / 53.8
• Overall Height (inches): 21"
• Overall Depth, Straight (inches): 28.5"
• Blade Angle (degrees): +/- 28
• Moldboard Thickness (inches): .12"
• Cutting Edge (inches): 5/8" x 6" bolt-on
• Blade Oscillation (degrees): +/- 4
• Cylinder Bore / Stroke (inches): 2.0" / 6.0"
• Cylinder Pins / Hinge Pins Diameter (inches): 1.0" / 1.25"
• Approximate Weight (pounds): 385 lbs
• Recommended Loader Capacity: Less than 1000 lbs
