Description

This 5000 Series Z Master zero turn mower features the amazingly comfortable redesigned MyRIDE® Suspension System that rides like no other machine in the industry. A powerful commercial-grade 26.5 hp Kohler® Command Pro EFI 747cc engine with 52 in. TURBO FORCE deck delivers impressive cutting results and durability at an outstanding value. The perfect zero turn for the landscape contractors and large acreage properties.

Features

• Cast Aluminum Spindle - Cools quickly for enhanced durability and performance.
• MyRide Suspension System - The suspended operator platform allows up to 3.6” of travel (depending on model) and reduces impacts, bumps and vibrations. Easily and quickly adjust rear shock ride settings to personal ride preferences, without tools!
• Exclusive Turbo Force Deck - High-capacity TURBO FORCE decks deliver unsurpassed strength, a superior cut, and increased productivity in extreme mowing conditions. Equipped with a patented adjustable baffle, TURBO FORCE decks can be fine-tuned in order to conquer changing turf conditions.
• 7-Gauge, High-Strength Steel - The TURBO FORCE deck is constructed of 7-gauge, high-strength steel which is 33% thicker and 32% higher in yield strength than ordinary 10-gauge commercial steel used in 7/10 decks. The combined effect is 75% stronger, so it easily handles the most demanding conditions and resists damage from impacts and abrasion.
• A Flat Crisp Cut with Precision Blades - (.250) thick precision blades resist flexing to provide a flat, crisp cut. High-strength, heat-treated alloy steel survives impacts and provides resistance to the rapid wear commonly associated with abrasive conditions. Options include Recycler® and Atomic® mulching blades, medium sail Bahai blades, and low sail sand blades.
• Rubber Discharge Chute - High performance rubber discharge chute allows for close trimming without damaging chute or landscape structures. Patented design provides exceptional clipping dispersion.
• Folding Rollover Protection System ROPS - A Rollover Protection System (ROPS), complete with seat belt, comes standard for operator protection in the case of accidental rollovers and tipovers. In situations where sufficient vertical clearance is not available, such as loading on an enclosed trailer, the ROPS can be temporarily unlocked and folded down.
• Patented Adjustable Baffle - Allows operator to achieve maximum cutting performance by fine-tuning deck to conquer changing conditions, unique job sites or different times of the season. In extreme conditions, the baffle can be opened in order to conserve power and achieve faster mowing speeds. In less demanding conditions, the baffle can be closed to yield micro-sized particles and maximize discharge velocity.
• Smooth, Powerful Response - The new unitized pump and wheel motor use proven commercial hydraulic components while eliminating hoses and other potential leak points. You'll get a smoother, faster response while enjoying an even more reliable machine.
• Smarter Design in a Bull-Nose Bumper - 7-gauge bull-nose bumper not only protects against frontal impacts, but also contains an integral underskirt to minimize blowout of debris and dust. The bottom, leading edge of the deck is raised 1/4" (6 mm), allowing grass to stand more upright when entering the cutting chamber, ensuring a level cut. Leaf "plowing" during spring and fall clean-up also is significantly reduced.
• Operator Information Center - The instrument panel includes a digital hour meter, fuel gauge, and voltage meter, as well as diagnostic indicators for the safety interlock system.
• Horizon360 Business Management Software - Managing and growing your business is hard work. Using a business management software system shouldn't make it harder. That is why we built Horizon360. If you can type and point/click a mouse, you have all the skills required.

Specifications

• Adjustable Discharge Baffle: Standard, Tools-Free
• Adjustment: 5-point adjustment on rear shocks
• Air Filter: Heavy-Duty Canister Air Cleaner
• Anti Scalp Wheels: 6 Standard, 1 Optional
• Armrests: Standard
• Blade Tip Speed: 18,500 ft/min / 5,638 m/min
• Blades: 0.204 in. (0.5 cm) Heat-Treated Steel
• Box Dimensions:
• Imperial: 91 in. x 70.5 in. x 52.5 in.
• Metric: 213.1 cm x 179.1 cm x 133.4 cm
• Carrier Frame: 3 in. x 1.5 in. x 10 gauge (7.6 cm x 3.8 cm x 10 gauge)
• Caster Tires: 13 in. x 6.5 in. - 6 in. (33 cm x 16.5 cm - 15.2 cm) Flat-Free Semi-Pneumatic
• Comfort Platform: MyRIDE® Suspension System
• Deck Design: 80-grade 7-Gauge 52" TURBO FORCE® with Bull-Nose Bumper
• Deck Material: 7-Gauge Steel
• Deck Size: 52 in. / 132 cm
• Discharge Chute: Rubber
• Drive System: Hydraulic Unitized Pumps and Wheel Motors
• Drive Tires: 23 in. x 9.5 in. - 12 in. (58.4 cm x 24.1 cm - 30.5 cm)
• Engine: 26.5 hp* Kohler® Command Pro EFI 747 cc
• Engine Brand: Kohler
• Engine Displacement: 747 cc
• Engine Horsepower: 26.5 hp
• Forward Ground/Transport Speed: Up to 10.0 mph / 16.0 kph
• Front Bumper: Reinforced Bull-Nose
• Fuel Capacity: 12 gal. / 45.4 L / 48 qt.
• Fuel Type: Gasoline
• Height of Cut: 1.0 - 5.5 in. / 2.5 - 14.0 cm
• Hour Meter: Standard
• Hydraulic Fluid: Premium Synthetic
• ISO Mounts: Qty 4, 2.5 in. 3-D Isolation Mounts
• Platform Travel: 3.6 in. / 9.1 cm
• Product Type: Zero Turn Mowers
• Product Use: Commercial
• Roll-Over Protection System (ROPS): Folding; Standard
• Seat: Handcrafted Deluxe Suspension Seat with Arm Rests Featuring Bullhorn Accent
• Shocks: 1 Front Center / 2 Rear
• Spindle Bearings: Maintenance-Free
• Spindle Housing: 9 in. / 22.9 cm Diameter Cast Aluminum
• Start Type: Electric
• Steering Controls: 1-5/8" (4.1 cm) Diameter Grips; Adjustable, Dampened
• Weight: 1,137 lbs / 515.7 kg
