Description
Description:
Get the job done better, faster and easier with the Stand-On SprayMaster.
The updated design creates more stability and balance resulting in less turf tear up and the flip up hopper allows for easy maintenance. Maximize ground coverage and reduce fill-up stops with two spay tanks with up to 60-gallon capacity, 250-pound hopper and
5-gallon fuel tank.
MAXIMUM OF 4.0 Acres COVERED PER HOUR LARGE CAPACITY.
Maximize ground coverage and reduce fill-up stops with two spray tanks that hold up
to 60 gallons, 250-pound hopper capacity, and a 5-gallon fuel tank.
Features:
Maintenance is a breeze
LEAN-TO-STEER
SPRAYMASTER
60 GALLON STAND-ON
Specifications:
POWER AND DRIVE SYSTEM
Engine: Kohler 21 hp Twin Vanguard
Engine Orientation Horizontal
Fuel Capacity Gas: 5 Gal (18.9 L) w/fuel gauge
Electric Start: Yes
Transmission Hydrostatic
Maximum Forward Speed:10 mph (16.1 mph)
SPREADER SYSTEM
Hopper Size: 250 lbs (113.4 kg)
Fertilizer Capacity: 225 lbs (102.1 kg) 2 Rear Boxes - 50 lbs (22.7 kg) each
Spread Width: Adjustable from 3'- 25' (0.9 - 7.6 m)
Deflector Shield: Molded Plastic
Spinner Motor: Electric
SPRAY SYSTEM
Pump Capacity: 5.3 GPM
Spray Capacity: 60 Gal (2 - 30 Gal)
Spray Width: 2, 4, 6, 8 or 10 ft (0.6, 1.2, 1.8, 2.4 or 3.0 m)
Boom: N/A 3-Section, Bi-Directional Breakaway Wings
Spot Spray Hose: 75 ft (22.9 m) Hose Reel
WEIGHTS AND MEASUREMENTS
Weight:912 lbs. (413.7 kg)
Height: 50" (127.0 cm)
Width: 52" (132.1 cm)
Length: 72" (182.9 cm)
