Description
OEM Replacement Steering Box (Right-Side) – 107847
Product Information
- Part Number: 107847
- Supersession: n/a
- Description: 107847 OEM Right-Side Steering Box * Does Not Come as an Assembly (Steering Arm, Spacer & Other Components are Not Included) - Is the Steering Box Component Only.
- Application & Usage: Steering Box Usage - The Operator's Forward & Reverse Movement of the Operator's Steering Control Levers (Fastened to the Steering Arm & Steering Arm Is Retained in the Steering Box) Dictates to the Steering Box Creating a Pivotal Movement of the Steering Box over the Retaining Pivot Pin - The Steering Box Pivotal Movement Then Transfers the Movement to the Hydraulic Linkage Connected to the Steering Box, Allowing the Operator’s Control Levers to Control the Machine’s Drive Functions.
Hustler OEM 107847 Steering Box Retains the Pivotal Position of the Steering Lever - If it Becomes Worn it Will Contribute to Uncontrollable Drifting in Neutral Position, Inconsistent Drive Tracking and Incoherent or Jerky Speed Acceleration and Deceleration.
- Common Associated Components:
107847 – Associated Individual Components
- 770867 - Insert Bushings * Replaceable Pivot Wear Component
- 107842 - Right-Side Steering Arm * Retained in the Steering Box - Retains the Operators Control Lever/Handle - Communicates and Controls the Pivot Motion of the Steering Box.
- 705178 - Bolt * Retains the Spacers and Lower Steering Arm
- 767954 - Washer * Retains the Spacers and Lower Steering Arm
- 086660 - Nut * Retains the Spacers and Lower Steering Arm
- 361295 (NOT AVAILABLE) - Steering Pivot Pin/Tube * Inserts into the Weldment Holes, Assist in Retaining the Steering Box & Enables the Steering Box to Pivot over it
Before You Order
Please verify that Part Number 107847 is the correct replacement for your equipment before placing your order.
Model Fit Chart
FasTrack (2007 – 2014 Models) * 48", 54", 60" Models Only
928267, 928275, 928291, 928374, 928382, 928481, 928502, 928520, 929786, 929794, 930107, 930115, 930123, 930123US, 930131US, 930149, 930149US, 930156US, 930164, 930164US, 930172US, 930784, 932319US, 932814, 932822, 932830, 932848, 932855, 932863
If you're unsure, send us your model and serial number, and we'll be happy to verify the correct part before you order.
Why Choose Genuine OEM Parts?
| ✓ | Built to the manufacturer's exact specifications |
| ✓ | Guaranteed fit with no modifications required |
| ✓ | Designed for maximum performance and durability |
| ✓ | Maintains the safety and reliability of your equipment |
| ✓ | Manufactured using high-quality materials |
| ✓ | Helps reduce downtime caused by poor-fitting replacement parts |
| ✓ | Protects the value and longevity of your equipment |
Choosing genuine OEM parts helps ensure your machine continues to operate as the manufacturer intended.
Whether you're performing routine maintenance or repairing a broken component, using genuine OEM parts helps maintain the reliability and performance of your equipment.
Keep your equipment performing the way it was designed with this genuine OEM replacement part. Manufactured to the original equipment manufacturer's specifications, this part is engineered for the proper fit, dependable performance, and long service life.
Fast Shipping from Hilly Ridge Sales & Service
Your order is shipped by a knowledgeable outdoor power equipment dealership—not a general warehouse.
Every order is carefully packed, and our experienced parts specialists are available to help if you have questions before or after your purchase.
Thank you for choosing Hilly Ridge Sales & Service for your genuine OEM parts needs.
Part Number: 107847
Description: 107847 OEM Right-Side Steering Box * Does Not Come as an Assembly (Steering Arm, Spacer & Other Components are Not Included) - Is the Steering Box Component Only.
