Description:

POWERFUL PERFORMANCE AND COMFORT



Engineered for top-tier performance and operator comfort, these tractors have the power you need to make light work of the heaviest jobs.

Specifications:



Engine:

• Power: 62 hp @ 2100 rpm
• Displacement: 161.6 in³ (2650 cc)
• Aspiration: Turbocharged
• Cooling: Water-cooled
• Bore: 3.78 in
• Stroke: 4.8 in
• Cylinder Liners: 3
• Fuel System: Fuel Injection (Direct)
• Fuel Type: Diesel




PTO:

• Type: 2-Speed Independent Single Lever type 1 PTO (dry clutch)
• Rear PTO RPM: 540/540E
• PTOHP (kW): 53.5 hp (39.9)



Drivetrain:

• Number of Speeds: 15F x 15R
• Transmission: Full Synchro Mesh with Forward / Reverse Power Shuttle and Constant Mesh Range
• Clutch: Mechanical shuttle with dry clutch
• Max Speed: 21.4 mph



Brakes:

• Brake System Type: Oil immersed
• Diameter: 8.75 in



Wheels & Tires:

• Tires, Front Specification: AG: 11.2 x 24 | IND: 43 x 16-20
• Tires, Rear Specification: AG: 16.9 x 30 | IND: 18.4-28



Electric:

• Battery: 12 V, 925 CCA
• Alternator: 12 V, 55 A (External Fan)



Hydraulics:

• Type: Open Center with Position and Draft Control, Telescoping Stabilizers and Flex Links
• Maximum Total Flow: 15.7 gpm
• Total Pump Output: 11.1
• 3-Point Hitch: CAT I & II
• 3-Point Hitch Lift Capacity: 5952 lbs



Dimensions:

• Overall Length: 152.7 in
• Overall Width: 82 in
• Overall Height: 106 in
• Wheelbase: 87.4in
• Ground Clearance: Minimum: 15.5 in
• Turning Radius: 12.5 ft
• Weight: 6416 lbs



Loader:

• Max Lift Height: 133 in
• Loader Lift Capacity: 3609 lbs
• Digging Depth: 5.5 in

Width	Weight	Height	Length
82 Inches	6416 lbs	106 inches	152.7 inches
