Description

As versatile as it gets

Tough-as-nails, these robust tractors provide professional-grade strength. Customizable for diverse tasks, ideal for agriculture, maintenance, and industrial or construction sites, ensuring versatile performance.

Features

• Ultimate Convenience with Synchromesh Transmission
• Supreme Comfort
• The Only One Size Fits All Tractor
• Unlock Greater Value with Our Extensive Range of Standard Features

Specifications

• Engine Type: Four-stroke, Turbocharged, Direct Injection, Water Cooled Diesel Engine
• Engine HP [kW] @ RPM: 55 @ 2300
• Displacement [in3 (cc)]: 166.2 (2723)
• Number of Cylinders: 4
• Fuel Tank [Gal (L)]: 17.1 (64.7)
• Bore & Stroke [in]: Bore: 3.78, Stroke : 4.8
• Transmission Type: Full Synchromesh with forward/reverse sychro shuttle & constant mesh range
• Number of Speeds: 12F / 12R
• Clutch: Dual Dry with Cerametallic Lining
• Max Speed (mph): 17.9
• Brakes: Fully-enclosed, 7-in Diameter, Dry Disc
• PTO Type: Independent
• Rear PTO RPM: 540 @ 2300 / 540E 1725
• PTO HP (kW): 47 @ 2300
• Hydraulic Type: Open center; Adjustable lower links with stabilizer
• Maximum Total Flow [GPM (L/min)]: 13.3
• Total Pump Output, Main (GPM): 8.71
• Total Pump Output, Steering (GPM): 4.62
• 3-Point Hitch: CAT I & II w/ Telescopic Stabilizers & Flex Links
• 3- Point Hitch Lift Capacity @ 24" aft [lb (kg)]: 3748
• Battery: 12-volt; 925 CCA
• Alternator: 12-volt; 55 amp
• Overall Length [in (mm)]: 136.6 (3470)
• Wheelbase [in (mm)]: 77.9 (1979)
• Turning Radius [ft (m)]: 10.8 (3.29)
• Overall Width [in (mm)]: 74.8 (1900)
• Overall Height [in (mm)]: 60.6 (1540)
• Minimum Ground Clearance [in (mm)]: 16.4 (435)
• Weight [lb (kg)]: 5390 (2445)
• IND [Front/Rear]: 10.5 / 80 x 18 / 16.9 x 24
• Loader Model Number: 5155-4L
• Max Lift Height (in): 122
• Loader Lift Capacity [lb (kg)]: 3100
• Digging Depth (in): 8.7
