Description:



A SUB-COMPACT THAT IS WELL ABOVE ITS CLASS.

The 1100 series is the toughest, friendliest, and smartest tractors in the world. We challenge all weekend warriors to test their mettle. Novices will smile at an intuitive and informative cockpit. Phone app lovers will be pumped by its intelligent OJA software.



Ideal Uses:

• Planting a garden, landscaping projects, material handling, trenching, mowing lawn & pastures, spreading weed & feed, fence work, grading driveways, and clearing snow.



Key Features:

• Effortless Controls at Your Fingertips: Electronic PTO engagement for your mid and rear implements is ideal for those with arthritis and is designed to prevent accidental activation, improving operator safety.
• Unmatched Ride Quality: Try sitting on a tractor all day, and then you'll see why the 1100 comes with power steering standard and mComfort - the comfiest seat in its class. It offers outstanding support, featuring a superior form-fitting seat cushion and foldable armrests.
• Best-in-Class Loader Tractor: Our hydrostatic drive system (HST) eliminates gear shifting by safely engaging color-coded forward or reverse pedals. Combining HST with a super smooth joystick for loader-control makes fast and efficient loader work.
• Won't Stop Until You Stop: Using projector style headlights for best-in-class output, we offer bright, white lighting for after-dark chores.

Includes:

• Four Wheel Drive
• Foldable ROPS (Roll-Over Protection Structure)
• Hydrostatic Transmission
• Turf Tires
• Loader

• 60 in. Belly Mower

Specifications:



Engine / Motor:

• Type: Naturally Aspirated, Indirect Injection, Water-Cooled Diesel Engine
• Cylinders: 3
• Engine HP (kW) @ RPM: 22.8 (17.0) @ 2900

• Displacement: 67.2 (1102 cc)
• Bore & Stroke (in): Bore : 3, Stroke : 3.2
• Fuel Tank: 6.6 gal.


Electrical:

• Battery Capacity: 12.6V, 650 CCA
• alternator: 12V, 55 A

Transmission:

• Type: HST - 2 Range
• Number of Speeds: Infinite
• Clutch: N/A
• Max speed (mph): 7.3
• Brakes: Single Pedal

Hydraulic System:

• Type: Open Center with Position Control
• Maximum Total Flow GPM (LPM): 7.6 (28.7)
• Total Pump Output, Main (GPM): 7.4
• Total PumpOutput, Steering (GPM): 3.8
• 3-pt Linkage: CAT I
• 3-pt Lift Capacity 24-inch from pin (lb (kg): 771 (350)


PTO:

• Type: Independent Wet Clutch
• PTO HP (KW): 18.3 (13.6)
• Rear PTO RPM @ Engine RPM: 540 @ 2837
• Optional Mid PTO RPM @ Engine RPM: 2500 @ 2837

Dimensions:

• Overall Length in. (mm): 100.4" (2550)
• Overall Width in. (mm): 46.3" (1177)
• Overall Height OS in. (mm): 86.6" (2200)
• Overall Height Cab in. (mm): 80.5 (2044)
• Wheelbase in. (mm): 55.1" (1400)
• Ground Clearance in. (mm): 6.7" (169)
• Turning Radius with Brakes ft. (m): 7.2' (2.2)
• Weight (lb (kg)): 1620 (735)

Tires Sizes & Options:

• Industrial (Front / Rear): 18 x 8.5 - 10 / 26 x 12 - 12
• Turf (Front / Rear): 16x7.5-10 / 24x12-12

Loader: L11

• Max Lift Height (in): 73.2

• Lifting Capacity Full Height at Pivot Pins (lb / kg): 794 lbs / 360
• Digging Depth (in): 3.14

Mower: M1154

• Type: Side Discharge
• Cutting Width (in): 60"
• Cutting Height Range (in): 1" to 4"
• Transport Height (in): 5"
• Lift Linkage Type: 3-Point Lift Lower Links
• Height Adjustment: 3-Point Hitch Position Control Lever
• Number of Blades: 3
• Blade Tip Speed (fpm): 18032 ft/min
• Weight (lb): 330 lbs
• Adjustable Anti-Scalp Wheels: 4
