Description

A sub-compact that is well above its class.

The 1100 series is the toughest, friendliest, and smartest tractors in the world. We challenge all weekend warriors to test their mettle. Novices will smile at an intuitive and informative cockpit. Phone app lovers will be pumped by its intelligent OJA software.

Features

• Effortless Controls at Your Fingertips
• Unmatched Ride Quality
• Best-In-Class Loader Tractor
• Won't Stop Until You Stop

Specifications

• Engine Type: Four Stroke, Naturally Aspired, Indirect Injection, Water-Cooled Diesel Engine
• Engine HP [kW] @ RPM: 20.1 (15) @ 2900
• Displacement [in3 (cc)]: 67.2 (1102)
• Number of Cylinders: 3
• Fuel Tank [Gal (L)]: 6.6 (25)
• Bore & Stroke [in]: Bore : 3, Stroke : 3.2
• Cylinders: Four Stroke, Naturally Aspired, Indirect Injection, Water-Cooled Diesel Engine
• Transmission Type: HST - 2 Range
• Number of Speeds: Infinite
• Clutch: N/A
• Max Speed (MPH): 7.3
• Brakes: Single Pedal
• PTO Type: Independent Wet Clutch
• Rear PTO RPM: 540 @ 2837
• Mid PTO RPM: 2500 @ 2837
• PTO HP (kW): 13.9 (10.4)
• Hydraulic Type: Open center, full-live hydraulic with Position Control
• Maximum Total Flow [GPM (L/min)]: 11.2
• Total Pump Output, Main (GPM): 7.6 (28.7)
• Total Pump Output, Steering (GPM): 3.8
• 3-Point Hitch: CAT 1 with check chains
• 3- Point Hitch Lift Capacity @24" aft [lb (kg)]: 771 (350)
• Battery: 12.6V, 650 CCA
• Alternator: 12V, 55A
• Overall Length [in (mm)]: 100.4 (2550)
• Wheelbase [in (mm)]: 55.1 (1400)
• Turning Radius [ft (m)]: 7.2 (2.2)
• Overall Width [in (mm)]: 46.3 (1177)
• Overall Height [in (mm)]: OS 86.6 (2200) Cab 80.5 (2044)
• Minimum Ground Clearance [in (mm)]: 6.6 (169)
• Weight [lb (kg)]: 1620 (735)
• Tires - IND [Front/Rear]: 18×8.5-10 / 26×12-12
• Loader - Model Number: L11
• Max Lift Height (in): 68 / 1721
• Loader Lift Capacity [lb (kg)]: 794 (360)
• Digging Depth (in): 3 (80)
• Mower Type: Side Discharge
• Cutting Width (in): 54"
• Cutting Height Range (in): 1 to 4
• Transport Height (in): 5
• Lift Linkage Type: 3 Point Hitch Lower Links
• Height Adjustments: 3 Point Hitch Position Control lever
• Number of Blades: 3
• Blade Tip Speed (fpm): 18040 ft/min
• Weight (lb): 320
• Adjustable Anti-Scalp Wheels: 4
