Description:

Standard Features:

• GVWR: 2,990 lbs.
• Bed Width(s): 60", 72", 78", 83”
• Lengths Available:
• 60" Model: 8', 10'
• 72", 78", 83" Model: 10', 12', 14'
• Axle: 3,500 LB Straight, Dexter E-Z Lube
• Tires: 205/R15 LRC Radial Tires, Mod Wheel
• Spare Tire Mount
• Springs: Four Leaf Eye-To-Eye Springs
• Jack: 2,000 LB Jack
• Coupler: 5K, 2" A-Frame Coupler
• Fenders: 9" Rolled Fenders
• Chassis: 4” Channel Chassis
• Tongue: 4” Structural Channel Wrapped Tongue
• Crossmembers: 2" X 2" Angle Crossmembers, 24” On Center
• Decking: Treated Pine Decking
• Wiring: Industrial Grade Sealed Wiring Harness, LED Lights
• Finish: Sand Blasted, Degreased, Acid Washed, Sealer Rinsed, Sherwin Williams Powder Coat for a High Gloss & Protective Finish

Options:

• Tire Options:
• 205/R15 LRC RADIAL, Silver Mod Wheels
• 205/R15 LRC RADIAL, Black Mod Wheels
• Jack Options:
• 2,000 LB Set Back Jack
• 7,000 LB Dropleg Set Back Jack (72", 78", 83" Models)
• Tail Options:
• 30" Tube Gate, 6GA Expanded (One Spring Standard)
• 48" Tube Gate, 6GA Expanded (Two Springs Standard)
• 2' Wood Dovetail (72", 78", 83" Models)
• Side Mount ATV Ramps (72", 78", 83" Models) [14' Length Only]
• 60" X 48" Tube Side Gate, 6GA Expanded [12' & 14' Lengths]
• Top Rail Options:
• 2" X 2" Angle Top Rail & Uprights
• 2 1/2" X 1 1/2" Tube Top Rail & 2" X 2" Tube Uprights
• Side Options:
• 20" Removable Three Board Sides
• 23" V-Crimped Solid Metal Sides
• Other Options:
• Radial Spare Tire and Wheel Mounted on Trailer
