Description:
CALL FOR DEMO PRICING!
Powerhouse that Delivers Unrivaled Performance.
The HyperDrive® features Hustler’s exclusive HyperDrive transmission system – the largest, most durable drive system in the industry and, it’s backed by a 3,000-hour drive system warranty.
Features:
- VX4 Deck: Fabricated 7 ga. steel engineered for extreme vacuum for performance and cut quality.
- Foot Operated Deck Lift: Easily adjust your cutting height between 1”- 5.5” with your foot.
- 13M Suspension Seat: High-back seat with adjustable armrests and 3-inch travel range.
- SmoothTrak Steering: Precision control to help trim and maneuver easily around obstacles.
- Ample Torque: Danfoss DDC-20 pumps and Parker TG wheel motors.
- Easy Serviceability: Flip-up seat pan, removable floor pan, and vented pulley covers for easy and simple maintenance.
Specifications:
Key Specifications
- Engine Manufacturer: Vanguard Big Block EFI Oil Guard
- Engine Horsepower: 40 hp
- Transmission: Danfoss DDC-20 Transmission w/ Parker TG wheel motors
- Fuel Capacity: Dual fuel tank w/ 12 gallon total capacity
- Ground Speed (FWD): Up to 16 mph
- Cutting Width: 72 in
- Cutting Height: 1" to 5.5"
- Front Tire: 13 x 6.5-6
- Drive Tire: 26 x 14-12
- Warranty: 5 Year / 1200 Hour (First 2 Years No Hour Limit)
Engine
- Engine Manufacturer: Vanguard Big Block EFI Oil Guard
- Engine Horsepower: 40 hp
- Displacement: 993cc
- Cooling: Air Cooled
- Engine Warranty: 3 Year Limited
Drive System
- Type: Dual Hydrostatic
- Transmission: Danfoss DDC-20 Transmission w/ Parker TG wheel motors
- Hydraulic Lines: Stainless steel Parker Seal-Loc Technology
- Reservoir Capacity: 3 gallons
- Hydraulic Cooling: Oil Cooler w/9" fan
- Engine Warranty: 3 year Limited
- Fuel Capacity: Dual fuel tank w/ 12 gallon total capacity
- Ground Speed (FWD): Up to 16 mph
- Parking Brake: Integrated with steering levers
General
- Seat: I3M Suspension Seat (adjustable armrests & back)
- Cup Holder: Yes
Dimensions
- Front Tires (in): 13 x 6.5-6
- Drive Tire (in): 26 x 14-12
- Weight (lbs): 1686-1750 lbs
- Height (in): 47.8, 73.5 w/ROPS in
- Length (in): 92 in
- Width W/ Chute Up (in): 78 in
- Tire-To-Tire Width (in): 60 in
- Productivity (Acres Per Hour): 9.31 aph
Warranty
- Warranty: 5 Year / 1200 Hour (First 2 Years No Hour Limit)
