Description:



The ZT5000 is an ideal fit for landscapers and homeowners who need a solid step up from an entry-level commercial mower.

Features:



With its incredible quality of cut courtesy the AirFX deck, commercial-grade transmission, and large drive tires, the ZT5000 is built for professional landscapers who demand the most from their machines, day after day.

• 23.5-hp Kawasaki FX series engine provides commercial-quality performance and outstanding durability.
• The bullnose AirFX™ cutting deck provides a phenomenal quality of cut and even clipping dispersal.
• Commercial-grade Hydro-Gear® ZT-3800 transaxles deliver the performance and torque required for all-day mowing.
• High-back suspension seat and almond shaped handles provide operator comfort.
•   Large 7.8 gallon fuel capacity reduces the time required to stop and refuel.

Specifications:



Key Specifications

• Mower Deck: AirFX Dual 10-gauge layer top with 3-gauge and 7-gauge brackets throughout
• Width: 61"
• Cutting Height: 1.5-4.8 in / 38-121 mm

Engine

• Horsepower: 23.5 hp
• Displacement: 726 cm³
• Engine Model: Kawasaki FX730V Gas Engine
• Fuel Capacity: 7.8 gal
• Emissions Tier (EPA): Tier 4

Performance

• Weight: 1043 lbs

Transmission

• Type: Hydro Gear ZT-3800 Hydrostatic
• Pump Displacement: 11 cm³
• Oil Capacity: 4 qt liq us

Electrical

• Clutch: 125 ft·lbf

Frame

• Front/Rear: Welded 7-gauge Steel; 1.5- x 2.5-inch Steel Tubing
• Length: 81.7 in

Wheels

• Drive Wheels: 24 x 10.5-12
• Front Castor Wheel Size: 13 x 6.5-6
• Caster Arm Attachment: Welded to Frame
