Description:

When you have more acres to maintain, you need more commercial-grade features to keep you on top. With the ZT3500, that comes standard.

Convenient maintenance

Standard 7-gauge steel frame

23 inch drive tires offer great control and a smooth ride

Designed for maximum comfort

High-back, full-mechanical suspension seat

Features:

COMFORT

• COMFORT AND CONTROL ALL DAY LONG: Experience ride comfort and intuitive operation like never before. The comfort command center optimizes the zero-turn mowing experience by putting responsive, ergonomically designed controls right where you need them – at your fingertips. When tackling tough jobs, the comfortable suspension seating and innovative anti-vibration technology will give you hours of unmatched ride comfort.

DURABILITY

• TOUGH JOBS. TOUGHER EQUIPMENT: You expect your machines to be as resilient as you and your crew are. That’s what you get from Bobcat zero-turn mowers. They’re built with heavy-duty, tubed steel framing that provides maximum durability to keep you on the job – and out of the shop. Our mowing decks, constructed with heavy-gauge fabricated steel, also are tough enough to handle everything commercial jobs can dish out.

PERFORMANCE

• PRO-GRADE ENGINE PERFORMANCE: Summon all the pro-grade power you need to get more done. With versatile, high-performance Kawasaki engines ranging from 23 hp to 37 hp, you get the engine performance you need to power through job after job – faster and more efficiently. Bobcat zero-turn mowers deliver the power and speed you need for hours of uncompromising mowing that leaves your work a cut above the rest.
• COMMERCIAL-GRADE TRANSMISSION: Bobcat zero-turn mowers feature superior Hydro-Gear® hydrostatic transaxles that deliver more torque, more output, more speed as well as smooth and steady mowing power - whenever you need it. Shift into high gear with maximum output torque and ground speeds. Step on the gas and see how a Hydro-Gear drive system keeps your machine’s transaxles performing at optimum output levels with improved control while reducing vibration and noise. The Hydro-Gear drive system is a major shift forward.
• ENGINEERING THE PERFECT CUT: There’s a lot that goes into engineering the perfect cut – and it goes beyond just the cutting blade. It takes ingenuity, innovation and intelligence working in harmony. From deep deck designs and their unique geometries to patented baffle, airflow and vacuum-seal technologies – Bobcat zero-turn mower cutting decks deliver a quality of cut virtually no other zero-turn mower can.
• EXTRA FUEL CAPACITY: Extra fuel capacity lets you stay focused on what’s most important – your turf. The ZT3500 comes standard with rugged, roto-molded dual fuel tanks with capacity up to 7.8 gallons.

SERVICEABILITY

• MAINTENANCE MADE EASY: Easy to Own. Efficient to Maintain. You depend on your equipment. It’s your business, your lawn, your livelihood – and you don’t have time for downtime. Built for easy serviceability, Bobcat zero-turn mowers have intuitive access points to internal components that make maintenance quick and easy.

Specification:

GENERAL INFORMATION

Manufacturer

Bobcat

Model Year

2023

Model

ZT3500 61 in. Kawasaki FX730V 24 hp

Model Code

ZT3561SH

Color

White

BODY

Frame

Front / Rear - Welded 7-gauge steel; 1.5 x 2.5 in. steel tubing

Seat

High-back, spring suspension

Seat Adjustment

Fore-aft adjustment - Seat slide lever

DRIVETRAIN

Transmission/Drive

HG ZT-3400 hydrostatic transaxles

Travel Speed Forward

10 mph (16 km / h)

Travel Speed Reverse

3.5 mph (5.6 km / h)

Wheels/Tires

Caster arm attachment - Welded to frame

Drive Tires

Drive wheel - 23 x 10.5 - 12

Steering Tires

Front caster wheel size - 13 x 6.5 - 6

ELECTRICAL

Charging System

15 A

ENGINE

Engine Model

Kawasaki FX730V

Horsepower

24 hp

Displacement

726 cc (44.3 ci)

Pump - 12 cc (0.7 ci)

Fuel Capacity

8 gal. (30.2 l)

Oil - 1 gal. (4 qt.)

MEASUREMENTS

Length

79 in. (2,006 mm)

Weight

832 lb. (377.4 kg)

Mowing Width

61 in. (1,549 mm)

Mowing Height Range

1.5 - 4.875 in. (38 - 121 mm)

OPERATIONAL

Deck Construction

Mower - TufDeck™ Pro 10-gauge top with 7-gauge

Spindle supports; 7-gauge side skirts

Discharge

Chute - Flexible molded polymer

Blade Tip Speed

18,809 fpm

PTO Clutch

125 ft. lb. (556 N)
