Description
Hustler OEM 601715 Primary Mower Deck Belt is Crafted only from the Finest of Materials and Rigorously and Extensively Tested to verify it withstands the toughest of Operating Conditions. Expertly crafted from premium Aramids and/or Kevlar materials, the Hustler OEM 601715 Is made to Fit Hustler
- 72" 2018 - Current Super Z & Super Z HD Models (Rear Discharge VX4 Mower Deck - * REFER PART REFERENCE CHART)
- 54" 2015 - 2017 Super Z Models (Side Discharge VX4 Mower Deck - * REFER PART REFERENCE CHART)
- 72" Early Hustler Models with a Out-Font Mower Deck.
601715 Mower Deck Belt Serves as the Primary Belt to a Two Mower Deck Belt System for Rear Discharge Models. Don't settle for imitations or substitutes when you can have - worry-free, designed to fit options, knowing that your Hustler Mower Deck Belts are built, tested, and designed specifically to OEM Standards and Expectations. Please refer to the Images above; Product Specifications, Special Notes and the Model Fit guide below to ensure proper fit.
MOWER DECK BELT ASSOCIATED PART NUMBER REFERENCE
CLICK ON THE ASSOCIATED PART NUMBER TO BE REDIRECTED
Note: Below the Individual Part Numbers Under Each Family Type is a Belt Fit Chart that will List the Mower Deck Belt Part Number Combination that is Correct for each Select Model Number. Using the Mower Deck Belt Chart Click on anyone of the Associated Part Numbers to be Redirected as Needed.
54" Super Z (Side DISCHARGE MODELS)
- 782292 - 54" Super Z (2023 - Current)
- 606873 - 54" Super Z (2018 - 2022)
- 601715 - 54" Super Z (2015- 2017)
- 797928 - 54" Super Z (Pre 2011 - XR7 Mower Deck)
72" Super Z & Super Z HD (REAR DISCHARGE MODELS)
Note 1: Super Z and Super Z HD 72" Rear Discharge Models Require Two Mower Deck Belts. The Primary Belt Travels from the Engine to the Mower Deck and Around Select Pulleys - Whereas the Secondary Mower Deck Belt is used only on the Mower Deck Itself between Mower Deck Pulleys.
- 601715 - 72" Super Z & Super Z HD (2018 - Current) Primary Belt
- 797928 - 72" Super Z & Super Z HD (2013 - 2017) Primary Belt
- 782292 - 72" Super Z (2011- 2012) Primary Belt
- 603422 - Secondary Mower Deck Belt For all Listed Models
Specification
|
Product Number: |
601715 |
|
Brand: |
Hustler |
|
Length: |
NA |
|
Width: |
5/8 IN |
|
Height: |
NA |
|
Weight: |
1.785 LB |
Model Fit:
54" Super Z (2015 - 2017 Models VX4 Side Discharge Mower Deck)
Model Numbers: 933457, 934984US, 934992
72" Super Z and Super Z HD (Approximately 2018 - Current Models VX4 Rear Discharge Mower Deck)
Model Numbers: 936955, 937052, 940049, 941203, 941286, 941567, 942912, 943043, 943944, 944033
Early Model 72" Hustler (OutFront Mower Deck) * No Listed Model Numbers
