Description
Toro OEM 140 2748 Height of Cut (HOC) Decal is a Numerical Decal and Allows the Operator to easily Make Their Preferred Selection of Height of Cut Setting. Toro OEM 140 2748 is Installed on the Front-Side Surface of the (HOC) Bracket and Fits Toro Select Late 42" Timecutter ZS, MX, 4200, Standard, My-Ride and Battery Models (Models with Cast Aluminum Axles) Select Late 50" Timecutter MX, My-Ride Models (Models with Cast Aluminum Axles). Please refer to the Images above; Product Specifications, Special Notes, and the Model Fit guide below to ensure proper fit. For Additional Part Number References Refer to the Associate Parts References Chart Below.
ASSOCIATED PART REFERENCES FOR PART NUMBER 140-2748 ONLY
CLICK ON THE ASSOCIATED PART NUMBER TO BE REDIRECTED
- 139-2350-01 - HEIGHT OF CUT (HOC) BRACKET- (A Slotted /Toothed Bracket that Fastens to the Frame of the Mower and Allows the Mower Deck Lift Lever to Travel through it, enabling the Mower Deck Lift Lever to Rotate Up and Down and Allowing it to Rest into the (HOC) Brackets Slots/Teeth at the Operators Preferred Height Selection). x1 Per Mower Deck Lift Lever
Specification
|
Product Number: |
1402748 |
|
Brand: |
Toro |
|
Length: |
7.750 IN (19.685 CM) |
|
Width: |
0.875 IN (2.223 CM) |
|
Height: |
0.030 IN (0.076 CM) |
|
Weight: |
0.004 LB (0.002 KG) |
Model Fit:
42” TIMECUTTER ZS Series – Model Numbers – (* Model Numbers 74677, 74683, 74685, 74687)
42” TIMECUTTER MX Series – Model Numbers – (* Model Numbers 74690, 74691)
42” TIMECUTTER 4200 & ZR 4200 Series – Model Numbers – (* Model Numbers 74679)
42” TIMECUTTER (My-Ride) Series – Model Numbers – (* Model Numbers 74692)
42” TIMECUTTER (Standard & My-Ride - Battery) Series – Model Numbers – (* Model Numbers 75642)
50” TIMECUTTER MX Series – Model Numbers – (* Model Numbers 74694, 74695)
50” TIMECUTTER (My-Ride) Series – Model Numbers – (* Model Numbers 74696)
