Toro OEM 140-2701-03 Rear Deflector Baffle Fits Select Toro 42" Timecutter Standard and MyRide Models (Models with Replaceable Cast Aluminum Axle's and Fabricated Mower Decks).

The Toro OEM 140 2701 03 Rear Deflector Baffle is a bolt-in baffle engineered to optimize airflow and vacuum for efficient discharge, ensuring a neatly trimmed lawn. Specifically designed to attach to the Inside Rear of the Mower Deck on Select Toro 42" Timecutter Standard & My-Ride Models (Models with Replaceable Cast-Aluminum Axle's and Fabricate or Welded Reinforced Mower Decks).







ASSOCIATED PARTS FOR PART NUMBER 140-2701-03 ONLY

CLICK ON THE ASSOCIATED PART NUMBER TO BE REDIRECTED





1. 139-2630 - CARRIAGE BOLT (Retains the Rear Deflector Baffle to the Back of the Mower Deck) x3 Per Rear Deflector Baffle
2. 119-4041 - NYLON LOCK NUT (Retains the Rear Deflector to the Back of the Mower Deck) x3 Per Rear Deflector Baffle







Specification

Product Number:	140270103, 140 2701 03
Brand:	Toro
Length:	27.125 IN (68.898 CM)
Width:	4.750 IN (12.065 CM)
Height:	3.500 IN (8.890 CM)
Weight:	4.054 LB (1.839 KG)





Model Fit:



TIMECUTTER



TIMECUTTER 42” MX Series – Model Numbers – 74690, 74691

TIMECUTTER 42” 4200 & ZR 4200 Series – Model Numbers – 74679

TIMECUTTER 42” (My-Ride) Series – Model Numbers – 74692
