Toro OEM 138-7232 Discharge Chute Torsion Spring Fits Late/Current 34" Timecutter Models - 36", 48", 54", 60" PROLINE Models - 48", 54", 60", TITAN and TITAN MAX Models.

The Toro OEM 138 7232 is specially made for the Toro Discharge Chute Application. This Discharge Chute Torsion Spring keeps the chute in the down position and provides adequate downward pressure, preventing it from bouncing on rough terrain. Discharge Torsion Spring 138-7232 is Used on Toro Late/Current 34" Timecutter Models - Late/Current 48", 54", and 60" TITAN and TITAN MAX Models - Late/Current 36", 48", 54", 60", PROLINE Models. Due to Model/Part Number Variation, For an Accurate Model/Series Break down of Part Number Usage Refer to the Model Fit Chart, Images and The Special Notes Below. Part Number 121-2983 Supersedes to Part Number 138-7232.







ASSOCIATED PARTS REFERENCES FOR PART NUMBER 138-7232 ONLY

CLICK ON THE ASSOCIATED PART NUMBER TO BE REDIRECTED





1. 109-8854 - PIVOT PIN (Retains Discharge Chute on Early/Late Models - Due to Part Number Variations Review Part Number Model Fit Chart to Ensure Correct Fit)

2. 138-7231 - PIVOT PIN (Retains Discharge Chute on Late/Current Models - Due to Part Number Variation Review Part Number Model Fit Chart to Ensure Correct Fit)
3. 109-5443 - DISCHARGE CHUTE (Early 48" and 52" TITAN Z and G4000 Models 74813, 74815, 94818, 725058076 - Review Part Number Model Fit Chart to Ensure Correct Fit)
4. 114-1651 - DISCHARGE CHUTE (Early 48" and 52" TITAN Z Models 74812, 74814, 74816, 74818 - Review Part Number Model Fit Chart to Ensure Correct Fit)
5. 117-1270 - DISCHARGE CHUTE (Early/Late 48", 54", 60" TITAN MAX MX, ZX Models and Late/Current PROLINE HDX Models - Review Part Number Model Fit Chart to Ensure Correct Fit)
6. 147-3015 - DISCHARGE CHUTE (Late/Current 48", 54", 60" TITAN Standard, My-Ride, MAX and ZXM Models - WITH I-BEAM FRAMING - Review Part Number Model Fit Chart to Ensure Correct Fit)
7. 133-1212 - DISCHARGE CHUTE (Late 60" MX - 48", 54", 60" HD Timecutter - Select Late/Current (Standard) PROLINE Models - Models Review Part Number Model Fit Chart to Ensure Correct Fit)
8. 121-0739 - DISCHARGE CHUTE (Select Late 34", 42", 50", 54" MX, ZS, SWX Timecutter Models - Review Part Number Model Fit Chart to Ensure Correct Fit)
9. 140-3548 - DISCHARGE CHUTE (Select Late/Current 34" Timecutter Models - Review Part Number Model Fit Chart to Ensure Correct Fit)







Specification

Product Number:	1212983, 1387232
Brand:	Toro
Length:	3.250 IN (8.255 CM)
Width:	2.500 IN (6.350 CM)
Height:	1.500 IN (3.810 CM)
Weight:	0.073 LB (0.033 KG)





Model Fit:



TIMECUTTER 34” (STANDARD) Series – Model Numbers – 75734, 77301



TIMECUTTER 42” SWX Series – Model Numbers – 74787

TIMECUTTER 42” MX Series – Model Numbers – 74640, 74642, 74760, 74765, 74766

TIMECUTTER 42” ZS Series – Model Numbers – 74390



TIMECUTTER 48” HD Series – Model Numbers – 75201, 75210, 75211, 74886, 74866, 74864

TITAN 48” Standard, My-Ride, ZXM Series (Current Models With I-Beam Framing) Series – Model Numbers – 76401, 76411, 76420, 76425, 76448

TITAN 48” Z (Late Model – Tube Framing) Series – Model Numbers – 74812, 74813, 74816

TITAN 48” Standard, My-Ride, X, XS, 4800, ZX (Late Model – Tube Framing) Series – Model Numbers – 74830, 74841, 74845, 74846, 74851, 74855, 74861, 74871, 74874, 74875, 74887, 74889, 74890, 74891, 74912, 74920, 75301, 75304, 75311, 75314



TIMECUTTER 50” MX Series – Model Numbers – 74641, 74643, 74770, 74771, 74775, 74776, 74778, 74727, 74768, 74772, 74773, 74774

TIMECUTTER 50” ZS Series – Model Numbers – 74395



TITAN 52” Z (Late Model – Tube Framing) Series – Model Numbers – 74814, 74815, 74818



TIMECUTTER 54” HD Series – Model Numbers – 75202, 75212, 74876, 74888, 74867, 74865

TITAN 54” Standard, My-Ride, ZXM (Current Models With I-Beam Framing) Series – Model Numbers – 76501, 76511, 76530, 76554

TITAN 54” Standard, My-Ride, MX, X, XS, ZX, 5400 (Late Model – Tube Framing) Series – Model Numbers – 74822, 74832, 74842, 74848, 74852, 74862, 74872, 74877, 74882, 74892, 74898, 74914, 74924, 75302, 75305, 75310, 75312, 75315



TIMECUTTER 60” MX Series – Model Numbers – 74777

TITAN 60” Standard, My-Ride, ZXM (Current Models With I-Beam Framing) Series – Model Numbers – 76604, 76605, 76614, 76635, 76660

TITAN 60” Standard, My-Ride, MX, ZX, 6000 Series (Late Model – Tube Framing) Series – Model Numbers – 74823, 74824, 74833, 74843, 74853, 74863, 74883, 74893, 75303, 75306, 75313, 75316

TITAN 60” MAX (Current Models With I-Beam Framing) Series – Model Numbers – 76606, 76607, 76608, 76609, 76610

TITAN 60” MAX (Late Model – Tube Framing) Series – Model Numbers – 76601, 76602



PROLINE  36”, 48”, 54”, 60”, Series – Model Numbers – 44409, 44410, 44423, 44424, 44427, 44430, 44436, 44448, 44454, 44460



G4000 Series (MOWER DECK)– Model Numbers – 94818, 725058076
