Toro OEM 117-9139 Upper Handle Section Fits Select 21" Toro Single Stage Power Clear and Quick Clear Snowblower (Only Model 38564) Models.

Please refer to the Images above; Product Specifications, Associate Part Chart and the Model Fit Guide below to Ensure a proper fit.



• PRODUCT NUMBER AND VARIATIONS: 117-9139, 117 9139, 1179139
• PRODUCT TYPE: Upper Handle Section
• SIZE: Length 17.400 in. - Width 1.900 in. - Height 29.400 in. - Weight 2.440 lbs.
• NOTES & DETAILS: Toro OEM  117-9139 IS COMMINLY USED - As the Upper of a Two-Piece Handle Assembly and Fastens to The Lower Handle Section - Enabling the Operator to Fold the Upper Handle Section Down for Transporting and Storage. The Upper Handle Section 117 9139 Also Contain the Clutch Bail to Engage and Disengage the Rotors/Auger.
• COMMON SERIES APPLICATIONS: Toro Select 21" Power Clear & Quick Clear (Only Model 38564) Snow Blower Models.



• MODEL FIT CHART:

SNOWBLOWER’S



QUICK CLEAR Series – Model Numbers – (* Model Numbers 38564)

POWER CLEAR Series – Model Numbers – (* Model Numbers 38451, 38452, 38587, 38593, 38741, 38742)





• ASSOCIATED PARTS CHART:



ASSOCIATED PARTS REFERENCES FOR PART NUMBER 117-9139 ONLY

CLICK ON THE ASSOCIATED PART NUMBER TO BE REDIRECTED



UPPER & LOWER HANDLE FASTNERS



1. 136-7130 - HANDLE LOCK BOLT/FASTNER (Retains and Locks Two-Piece Handle Assemblies from Coming Apart or Folding) x2 Per Handle Assembly
2. 107-3844 - CONTOUR WASHER (Shaped to contour the Handle and is Used Between the Handle and the Fastners to Protect the Handle and Support the Fastners) x1 Per Handle Lock Bolt/Fastner
3. 114-3779 - HANDLE KNOB (Retains the Handle Lock Bolt Fastner in the Handle Two-Piece Handle Assembly and Enables Operator to Easily Disassemble or Fold the Handle Assembly) x2 Per Handle Assembly



UPPER HANDLE COMPONETS

1. 117-9136-03 - CLUTCH BAIL (Inserts into the Upper Whole's in the Upper Handle Section and Enables the Operator to Engage and Disengage the Rotors/Auger) x1 Per Handle Assembly
2. 94-2577 - ROTOR/AUGER DECAL (Installed at the Top of the Handle within Operator's View) x1 Per Handle Assembly
3. 125-7938 - REFLECTIVE TAPE (Assembles on the Front -Side of the Upper Handle Section) x2 Per Handle Assembly *Select Models - *R-C (Contractor Grade) Series Only
